The JLCI-HVC5 (JLT-ESS-01) is a high-capacity, 100kW peak power Commercial Energy Storage System (ESS) featuring a 215kWh energy capacity. Designed for demanding industrial and commercial applications, it combines an advanced BMS with intelligent air cooling to provide a reliable, scalable, and efficient energy management solution.

Add to wishlist

Product Description

Item	Specification
Rated Battery Capacity	215kWh
Nominal Voltage	AC 400V
Charge & Discharge Rate	0.5CP
Cooling Method	Intelligent air cooling
Auxiliary Electrical Parameters	50Hz/60Hz
Fire Protection System	S-type aerosol
Anti-corrosion Level	C3
IP Rating	IP54
Operating Temperature Range	-20-50°C
Storage Temperature	-20-55°C
Operating Humidity Range	0-95% RH
Operating Condition	Max. 2 charges & 2 discharges per day
System Communication Interface	Ethernet/RS485/CAN
External Communication Protocol	Modbus TCP/IEC61850/Modbus RTU
Altitude	Within 3000m
Dimension (DWH, mm)	1740 * 1100 * 2330
Weight (kg)	< 2400
Certification	CE/EN IEC 6100/UN38.3
Installation Method	Outdoor
